MATERIAL TYPE:
A242 Welded Wire
PANEL DIMENSIONS:
Width: 60" (20 Wires)
Length: 120" (39 Wires)
Custom Sizes and Patterns Available Upon Request
WIRE SPACING:
Center to Center: 3.148"
Clear Opening: 3"
WIRE THICKNESS:
0.148 (12 Gauge)
TOLERANCE:
Tol +/-1/8 Nubs 1/8 Space +/-1/16 Wire +/-.002 Std Growth
Standard weld marks & heat discoloration @ all intersections
Inquire about sizes that are not shown in stock. Fill in the additional information box on the quote page.
Note: Corten Wire does NOT arrive pre-rusted. Weathering steel will rust naturally when exposed to the weather.
![Corten Welded Wire Mesh Dimensions](https://www.corten.com/wp-content/uploads/2023/06/corten-welded-wire-mesh-1024x576.jpg)
WHAT IS WELDED WIRE MESH?
Welded wire mesh is constructed with two orthogonal wires that are joined together at their intersections using a resistance welding process to form a grid. The line wires of the grid are guided through the welder using a pattern board. The machine drops cross wires into place and fuses them together to create the two distinctive planes that form welded wire mesh.
Notes:
Standard weld marks & heat discoloration @ all intersections
Inquire about sizes that are not shown in stock. Fill in the additional information box on the quote page.
Note: Corten Wire does NOT arrive pre-rusted. Weathering steel will rust naturally when exposed to the weather.
